MP-20x Telephone Adapter 152 Document #: LTRT-50609
User's Manual
Figure 12-1: Remote Management Interfaces
All configuration interfaces access the same internal configuration repository. The
configuration file represents the complete set of MP-20x configuration parameters. Specific
configuration interfaces (e.g. SNMP and TR-069) might support access only to a sub-set of
these configuration parameters.
At any time, the factory settings can be restored using the Web interface or by pressing on
the Restore Defaults push-button while MP-20x is being powered up.
The table below lists the main MP-20x configuration parameter groups:
Table 12-1: Main Configuration Parameter Groups
Group Description
VoIP
Parameters relating to the VoIP functionality (e.g. analog interface, SIP
signaling, voice and fax, media streaming)
WAN Interface
The main WAN Internet connection (this group is also referred to as the
"Quick Setup").
Network Connections
Configuration of all network connections (LAN and WAN), including
advanced connections such as VLANs.
Security
Parameters relating to the internal firewall.
QoS
Configuration of Quality of Service parameters such as priorities and traffic
shaping.
System / Advanced
Configuration of system parameters such as Remote Update and Remote
Access and advanced parameters such as Dynamic DNS, UPnP.
A typical set of parameters that a service provider may want to configure include the
following:
Remote access and/or automatic firmware and configuration update parameters
VoIP configuration: SIP proxy, line settings (User IP, Password)
QoS parameters (e.g. traffic shaping)
