Version 3.0.1 61 July 2010
MP-20x Telephone Adapter 5. Configuring VoIP Parameters
Table 5-7: Speed Dial Settings - via Proxy
Parameter Description
Speed Dial
Defines the number to dial.
Destination
Defines the entry's destination, in this case a proxy server.
User ID
Defines the user ID to call.
The figure below shows how a local line speed dial is configured from port ‘Line 2’ on MP-
20x to port ‘Line 1’ on MP-20x. The speed dial number 226 is now associated with Line 1
on MP-20x.
Figure 5-11: VoIP - Speed Dial - Local Line
Click OK; you're returned to the Voice Over IP' screen displaying the configured speed
dial (refer to the figure below, displaying how two local lines are configured for speed
dial).
Figure 5-12: VoIP - Speed Dial Settings - Local Line
