AudioCodes MP-20x User Manual

Version 3.0.1 55 July 2010
MP-20x Telephone Adapter 5. Configuring VoIP Parameters
Table 5-5: Services Tab Parameters Description
Parameter Description
Call Waiting
Enabled
Check to enable the Call Waiting feature.
Call Waiting SIP Reply
The response message sent when another call arrives while a call is in
progress. There are two possibilities: 180 Ringing or 182 Queued (default).
Enable Caller ID Type II
Checked to enable caller ID of a waiting call (Called Caller ID type 2).
Call Forward
Enabled
Enables call forwarding. The Call Forward feature permits a user to redirect
incoming calls addressed to him/her to another number. The user’s ability
to originate calls is unaffected by Call Forward.
Note: The Call Forward feature is functional only when MP-20x is
registered to a proxy.
Call Forward Type
Three types of Call Forwarding exist:
 Unconditional: When selected, incoming calls are forwarded
independently of the status of the endpoint.
 Busy: When selected, incoming calls are forwarded only if the endpoint
is busy, i.e., if all lines are active.
 No Reply: When selected, incoming calls are forwarded only if the
endpoint does not answer before a pre-configured timeout (see next
parameter).
Time for No Reply
Forward
If you specify 5 seconds for this parameter, for example, and 'No Reply' is
selected for parameter 'Call Forward Type' (see above), incoming calls are
forwarded only after 5 seconds lapse.
Note: This parameter is available only when "No Reply" is selected for the
parameter 'Call Forward Type'.
Key Sequence
The default is *72 but users can modify to any sequence of up to 2 digits,
i.e., *n or *nm.
Do Not Disturb
Enabled
Check this box to enable the Do Not Disturb (DND) feature. This feature
allows you to prevent incoming calls from ringing at your phone. When Do
Not Disturb is enabled, callers receive a busy signal or an announcement.
The DND is activated using the phone keypad. Default is disabled.
Key Sequence
The key sequence to activate/deactivate the DND feature.
