MP-20x Telephone Adapter 158 Document #: LTRT-50609
User's Manual
12.2.2.1 Configuring MP-20x via TR-069 and TR-104
TR-069 allows basic configuration of MP-20x. The configuration is defined in a hierarchical
tree-like structure according to the TR-069 standard.
12.2.2.1.1 Configuring the WAN Interface
Table 12-6: InternetGatewayDevice.WANDevice.i.WANConnectionDevice.i.WANIPConnection.i
TR-069/TR-104
Parameter
Configuration File
Parameter
Description
AddressingType mt_cwmp_param_wan_con
n_ip_addressing_type_get/
set
The method used to assign an address to the
WAN side interface of the CPE for this
connection:
“DHCP”
“Static”
ConnectionStatus mt_cwmp_param_wan_con
n_ip_status_get
Current status of the connection:
“Unconfigured”
“Connecting”
“Connected”
“PendingDisconnect”
“Disconneting”
“Disconnected”
ConnectionType mt_cwmp_param_wan_con
n_ppp_type_get
Specifies the connection type of the
connection instance:
“Unconfigured”
“IP_Routed”
“DHCP_Spoofed”
“PPPoE_Bridged”
“PPPoE_Relay”
“PPTP_Relay”
“L2TP_Relay”
DefaultGateway mt_cwmp_param_wan_con
n_ip_default_gateway_get/
set
The IP address of the default gateway for this
connection. This parameter is configurable
only if the AddressingType is Static.
DNSEnabled mt_cwmp_param_wan_con
n_ip_dns_enabled_get/set
Whether or not the device should attempt to
query a DNS server across this connection.
DNSOverrideAllowed mt_cwmp_param_wan_con
n_ip_dnsoverrideallowed_
get/set
Whether or not a manually set, non-empty
DNS address can be overridden by a DNS
entry received from the WAN.
DNSServers mt_cwmp_param_wan_con
n_xxx_dnsservers_get/set(
i)
Comma-separated list of DNS server IP
addresses for this connection. Support for
more than three DNS Servers is optional.
Enable mt_cwmp_param_wan_con
n_xxx_enable_get/set(1)
Enables or disables the connection instance.
On creation of a WANIPConnection instance,
it is initially disabled.
