Fig. 71 - 56
BPA filter has to be fixed with a cable tie as shown at Fig. 71 – 56.
Only the connector adapter (of PBA filter) is allowed to be used for fixation with the cable tie.
Fig. 71 - 57
The branch of GPC, MOK and GEN, CRS2 has to be fixed with a clamp to the oil filter housing
screws (8 Nm).
05
GPC
Alternator
MOK
03
Oil filter housing
03
05
BPA Filter
BPA
