Friction traces:
The gap between primary and secondary mass has to be checked. If there are traces of wear at the
surface of the primary mass, caused by friction of the secondary mass at the surface of the primary
mass, the two-mass-flywheel has to be replaced.
Fig. 85 - 41 Gap between primary (1) and secondary (2) mass
1
2
