Error detection and troubleshooting
Manual b maXX
®
BM1000
Document No. 5.07003.04
85
of 174
8
0505
hex
cF34 Temperature sensor
error
PWM
inhibit
m Return the b maXX
®
to the factory
0506
hex
Aerr Analog signal error P0806
m Check the wiring of ACI
0507
hex
oL Overload
The device detects exces-
sive drive output current.
NOTE:
The device can withstand
up to 150 % of the rated
current for a maximum of
60 seconds.
PWM
inhibit
m Check whether the motor is overloaded.
m Reduce torque compensation setting in
P0112.
m Use the next higher power model.
0509
hex
oL2 Overload 2
Motor overload.
P1213
m Reduce the motor load.
m Adjust the over-torque detection setting
to an appropriate setting (P1213 to
P1215).
050A
hex
HPF1 CC (current clamp) PWM
inhibit
m Return to the factory
050B
hex
HPF2 OV hardware error PWM
inhibit
050C
hex
HPF3 GFF hardware error PWM
inhibit
050D
hex
HPF4 OC hardware error PWM
inhibit
050E
hex
cF33 DC BUS (0 V or Lv)
checking error
PWM
inhibit
0512
hex
PtC2 Motor PTC temperature
error
P0122
m Check if the motor is overheated
m Check P0117 to P0122 settings
0513
hex
FbE PID feedback error P1368
m Check parameter settings (P1360) and
AVI/ACI wiring.
m Check parameter settings (P1381) offset
level for PID control.
m Check parameter settings (P1382) de-
tection time for PID offset level.
m Check parameter settings (P1368) for er-
ror or warning
Fault
code
Fault
name
Fault description Error
reaction
Corrective actions
