/FNCT R / W NOTHING,
POWER,
ABS, REL,
TOG- GLE,
PRESET,
MONI,
GFRES,
MEMFLAG,
MEAS,
TEST- GEN
Function during activation.
For further details please refer to the
table "Control Inputs - GPI Functions"
below.
/PRM /... Parameter and values for the functions
mentioned before
/OFF ... (same as above but for the
deactivation of control inputs)
/IN2 ... (same as above but for the control
input 2)
/OUT1 /
STATE
R / W ON, OFF State of the Control Output
/ON /TIME R / W 0...10.0 [s] Delay / debounce time for the
programmed condition
/FNCT R / W NOTHING,
POWER,
ABS,
TEMP, VU,
CTL_IN,
ERR- FLAG,
MEMFLAG,
PRESET
Condition that activates a control
output.
For further details please refer to the
table "Control Outputs - GPO
Functions" on this page.
/INV R / W ON, OFF Inverts the result of the programmed
condition
/SYNC R / W ON, OFF Lets you select whether the control
outputs can be synchronized using a
special CAN-command.
/PRM /.. Parameters and values for functions
mentioned above
/OFF ... (same as above but for switching off a
control output)
/OUT2 ... (same as above but for the control
output 2)
/MEMFLAG /SET R / W NONE,
1...16
List of currently set Memo flags
IRIS-Net REMOTE AMPLIFIER | en 158
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
