Line Supervision The line supervision of the device can be controlled and supervised from this window.
AudioNet This window lets you configure the audio network and provides an overview of the current
fault status of the audio network.
HINT: This window is only visible if a CM-1 module is included in the configuration.
General Dialog
Double clicking on a DPM 8016 by default opens the General dialog box. Here, the user can make basic settings that
are necessary for flawless operation. All elements of the displayed DPM 8016 front panel are active in on-line mode and
correspond to the actual indicators on the unit.
Notice!
System language Korean or Chinese
For using system languages Korean or Chinese the call station firmware type “CST_Vx.x.xA” has to
be used. Please be patient when uploading this firmware to the call station.
IRIS-Net PROMATRIX 8000 | en 724
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
