Element Description
AUDIO NET
MASTER
Select the DPM 8016 from the Dropdown menu that should be used as master
in the audio network.
HINT: In large networks usage of a network metric, e.g. betweenness
centrality is recommended for selecting the master.
ENABLE Check this checkbox, if a redundant audio network is used.
DESTINATION Click the ... button to open the Destinations dialog. The Destinations dialog
allows selecting a zone/group. If there is an error in the audio network, the
audio signal is transmitted to the selected zone/group.
HINT: Selecting the “all” group is recommended.
At the occurrence of a type of error for which the checkbox DETECT is ticked,
the COLLECTED ERROR AUDIO NET flag is set at the same time.
The current condition of each type of error gets indicated. Green means no
error, red indicates that an error has been detected.
IRIS-Net PROMATRIX 8000 | en 786
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
