CM-1 Error in CM-1 module of the DPM 8016.
CM-1 PRIMARY
LINK
Error in the connection of the PRIMARY LINK interface to another network
device (e.g. switch, router, DPM).
CM-1 SECONDARY
LINK
Error in the connection of the SECONDARY LINK interface to another network
device (e.g. switch, router, DPM).
AUDIO NET BUS Error in audio network (CobraNet).
AUDIO NET
CONNECTION
Error in connection to audio network (Slave DPM has no Ethernet connection to
Master DPM).
AUDIO NET
COMPLETE
The number of devices connected to the audio network (Ethernet) is not
identical to the number of configured devices.
COLLECTED
ERROR AUDIO NET
This error is indicated as “AUDIO NET” error in the Supervision dialog.
