Audio Input Select one of the following audio sources for the announcement:
– Internal Mic
– External Mic
– External Line
Locked Behavior
(Active When
Locked)
Selecting this checkbox allows the user to press the button even though the call station has been
locked. The following parameters can be set independently from the default unlocked state.
Trigger Type Select the desired functionality for a button on a call station; available are:
– Push (pushbutton)
– Trigger (triggers a function)
Priority Select the button's priority (0 to 9).
Pre-chime Type Select the desired type of pre-gong (chime) signal. The list includes default signals and chime
signals uploaded to the MM-2 module (if available). Following default signals are available:
– No Prechime
– 1-Tone
– 2-Tone
– 3-Tone
– 4-Tone
– 2x2-Tone
– 2-Tone Pre-Chime
Selection
A switch of the type "Selection" allows configuring a SELECT button. Pressing the button on the call station selects the
Zones and/or Groups that have been configured here.
Element
Description
Destinatio
n
Clicking onto the button „..." opens the Destinations Dialog for selecting desired Zones and/or Groups.
Clear Key
A switch of the type "Clear Key" allows configuring an ALL/CLEAR button. Pressing the button on the call station
selects or deselects all Zones and/or Groups.
IRIS-Net
PROMATRIX 8000 | en 800
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
