FILTER and trigger list Select the trigger condition from the list. Enter a string (e.g. GPI) in the text field
FILTER to list only the conditions containing this string.
PAGING
EXISTING Select EXISTING to select an existing paging from the dropdown menu.
NEW/UPDATE Select NEW/UPDATE to edit the settings of the paging.
TYPE Select the paging type from the dropdown.
LABEL Enter the name of the paging.
PRIORITY Select the priority of the paging.
ALARM If the selected paging TYPE = ALARM you can select the alarm type from this
dropdown.
PRECHIME TYPE If the selected paging TYPE = ANNOUNCEMENT you can select the pre-chime
type from this dropdown.
CHIME TYPE If the selected paging TYPE = CHIME you can select the chime type from this
dropdown.
MESSAGE NR If the selected paging TYPE = EVAC Message you can select the message number
from this dropdown.
INPUT CHANNEL If the selected paging TYPE= ANNOUNCEMENT or TYPE = ALARM (and ALARM =
Extern) you can select the audio input channel for the paging.
DESTINATIONS Select the zones or groups of the paging.
STATIC Select a STATIC destination zone pattern for a CONDITION.
DYNAMIC When selecting a DYNAMIC destination zone pattern, it is only possible to select
one Call Station from the list (no multi selection). For DYNAMIC destinations, the
current selection of the referenced Call Station is used to start the signal when
the condition reaches the state “high” (for a high priority signal).
See Dynamic Destination behavior on a Call Station, page 766.
Keywords in condition list
Keywords can be selected from the condition list to start a signal:
Pagings.VCondition%d.Value where %d is replaced with an ongoing decimal number.
The “V” is short for “Virtual””, so this keyword can be considered as a “Virtual condition” to start a signal. The keyword
can be referenced by a Logical Key on a call station and allows to directly control a signal trigger without redirection
via the Task Engine. Thus, it is no longer required to create a V-LOGIC block in the Task Engine which is then used as a
condition in the Pagings dialog.
Logical keys can be explicitly used for Alarm Buttons on a Call Station.
See also Logical Key, page 974.
See also
– Configuration Dialog, page 974
– Pagings Dialog, page 765
– Pagings Dialog, page 766
Programs Dialog
The Programs dialog allows to configure 4 programs for background music.
IRIS-Net PAVIRO | en 944
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
