Element Description
CONDITION The condition that starts the background music, e.g. a switch connected to a GPI of
the device.
INVERT Set the checkbox to invert the condition that starts the back ground music.
SOURCE The source of the background music.
DESTINATIONS The destinations (zones or groups) of the background music.
REQUEST Indicates the current status (active or inactive)
Element Description
DELETE Press the DELETE button to delete the entry selected in the list.
UPDATE Press the UPDATE button to apply the settings in the lower section of the dialog to
entry selected in the list.
NEW Press the NEW button to create a new background music using the settings in the
lower section of the dialog and adds it to the list.
Element Description
CONDITION
FILTER and condition list Select the condition to start background music from the list. Enter a string (e.g.
GPI) in the text field FILTER to list only the conditions containing this string.
SOURCE
EXISTING Select EXISTING to select an existing source for background music from the
dropdown menu.
NEW/EDIT Select NEW/EDIT to edit the settings of the source.
LABEL Enter the name of the background music.
INPUT CHANNEL Select the audio input channel for the background music.
DESTINATIONS Select the zones or groups of the background music.
Interfaces Dialog
The Interface window allows configuring the different interfaces located on the rear panel of the device. All REMOTE
CAN BUS and CONTROL PORT settings can be made in here. Configuring the Ethernet interface is done under Network
Settings in the General window.
IRIS-Net PAVIRO | en 947
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
