Application Label Types
BBP
®
35/37 User’s Manual 146 Rev A
7. On the Legend screen, touch Legend line 1: data field, and enter the text to display on the
label.
8. You can add additional data in the Legend line 2: field, then touch Next .
You can add up to four graphics to the pipe marker label. The available graphics are divided
into categories.
To change to another category:
9. Touch Change Category .
10. Under Categories, touch the up/down arrows to view more categories in the list.
11. Touch the desired category to select it, then touch OK .
12. On the Graphics screen, touch the left or right double arrows to scroll through
the list of available graphics.
13. Touch the desired graphic in the list.
14. Repeat the above two steps to add another graphic.
15. When ready, touch Finish .
