System Specifications (BBP
®
35/37)
BBP
®
35/37 User’s Manual 2 Rev A
System Specifications (BBP
®
35/37)
The BBP
®
35/37 printer has the following specifications:
• Weight: ~35 lbs (~20 kg)
• Dimensions (W x H x D stored) : 18.5 in. x 11 in. x 14.2 in. (47 cm x 28 cm x 36 cm)
• Operating Temperature: 50 – 104°F (15 – 40°C)
• Relative Humidity: 15% to 80% RH non-condensing
• Storage: -4 - 122°F (-20°C to 50°C) at 15% to 90% RH non-condensing
• Voltage: 100 to 240 VAC, 50 to 60 Hz
• Print Resolution: 11.8 dot/mm, 300 dpi
• Ribbon Sizes: 4.0 in. (10.2 cm) and lengths of up to 200 ft (60.8 m) for monochrome
ribbon
• Tape Sizes: 0.5 in. to 4.0 in. width and lengths of up to 195 ft (B30C-4000-8423)
• Minimum label length (cut): 0.5 in. (12.7 mm)
• Maximum label length (continuous media):
- Single color : 102 in.
- Multi color : 48 in. (by swapping monochrome ribbons)
- Multi color : 14 in. (by using panelled ribbons)
Compatible Applications
The BBP
®
35/37 Label Printer is compatible with Brady Workstation software.
When used with this software package, the printer will automatically recognize all enabled and
compatible materials.
Note: Only B30 supplies will work with the BBP
®
35/37 printer.
Firmware Upgrades
Future upgrades to BBP®35/37 firmware can be downloaded from Brady’s website.
1. Access www.bradyid.com.
2. Click Support, then click Downloads.
3. Select BBP®35/37 from the list of products.
(See page 189 for instructions on upgrading your printer’s firmware from a USB flash drive or
from your PC.)
