Formatting a Label
Rev A 67 BBP
®
35/37 User’s Manual
In the Barcode dialog box, under Symbology:
3. Touch the up/down arrows in the scroll bar to the right of the barcode symbology to access
more barcode types.
4. Touch the desired barcode type.
5. Touch the Data value: field and enter the data the barcode represents.
Note: If a typed character is invalid for the active symbology, the typed character
does not display. The cursor remains in the position (does not move forward) until a
valid character is entered.
6. Select OK .
Change Barcode
To change the type of barcode after the barcode is established:
1. In the Editor, touch the barcode element.
2. In the Barcode control panel, touch Change Barcode .
3. In the Barcode dialog box, touch the desired barcode type and change any of the barcode
data as necessary.
4. When ready, touch OK .
Size
Sizing the barcode affects only the height (vertical length) of the barcode, from top to bottom.
To increase or decrease the height of the barcode:
1. In the Editor, touch the barcode element.
2. In the Barcode control panel, touch Plus to increase the height, or touch Minus
to decrease the height.
Note: The font type and size affects the height of the barcode. The barcode and the
human readable text must fit in the frame of the barcode element. As the size of the
human readable text increases, it decreases the height of the barcode.
