HSID Rollform Pipe Marker
To use an HSID Rollform Pipe Marker label type:
1. From the Home Page, touch More Label Types button , then touch HSID Pipe
Markers.
2. On the HSID Pipe Marker screen, touch Create New File .
3. On the Pipe Marker Style screen, touch Rollform .
4. In the Dimensions dialog, touch the Pipe diameter: data field and enter the diameter of the
pipe to which the label will be afixed.
5. In the Tape width: field, touch the desired Tape Width, then touch Next .
In the Pipe contents dialog box, choose the type of material that flows through the pipe.
6. Touch the up/down arrows to view more options in the list.
7. When found, touch the desired contents option to select it, then touch Next .
The material selected determines the pipe marker colors based on the selected color norm in
the Pipe Marker setup menu. (See page 143 for Pipe Marker setup.)
8. On the Legend screen, in the Chemical name: field, enter the name of the substance that
will flow through the pipe.
OR, in the displayed list:
Touch the name of the substance.
Whether you entered the substance name or selected it from the list, you can add additional
information to the chemical name field, such as special characters.
9. To enter special characters, touch the Chemical name: field where the special characters
should be placed.
10. Touch , then enter the character(s). See “Typing Special Characters” on page 56 for
more detail.
