Application Label Types
BBP
®
35/37 User’s Manual 166 Rev A
HSID Arrow Pipe Marker
To create an HSID Symbol or Arrow Tape pipe marker:
1. From the Home Page, touch More Label Types button , then touch HSID Pipe
Markers.
2. On the HSID Pipe Marker screen, touch Create New File .
3. On the Pipe Marker Style screen, touch Symbol or Arrow Tape .
4. In the Dimensions dialog, touch the Pipe diameter: data field and enter the diameter of the
pipe to which the label will be afixed.
5. Under Tape width: touch the desired Tape Width, then touch Next .
In the Pipe contents dialog box, choose the type of material that flows through the pipe.
6. Touch the up/down arrows to view more options in the list.
7. When found, touch the desired contents option to select it, then touch Next .
You can add a single arrow or symbol (graphic) to the pipe marker label.
8. On the Symbol Type screen, touch Arrow to add an
arrow to the label.
OR
Touch Symbol to add a graphic to the label.
If selecting Symbol, the Graphics screen displays. The available graphics are divided into
categories. To change to another category:
9. Touch Change Category .
10. Under Categories, touch the up/down arrows to view more categories in the list.
11. Touch the desired category to select it, then touch OK .
12. On the Graphics screen, touch the left or right double arrows to scroll
throught the list of available graphics.
13. Touch the desired graphic in the list.
14. When ready, touch Finish .
