Brady BBP 35 - Rollform Pipe Marker

Application Label Types
Rev A 145 BBP
®
35/37 User’s Manual
Rollform Pipe Marker
Rollform Pipe Markers use only continuous media. Rollform Pipe Markers include one to two
lines of text, repeated the length of the pipe marker, alternating at 90 degree and 270 degree
rotation. You can add up to four graphics, placed in predetermined locations. Graphics are
repeated and rotated along the length of the pipe marker, as is the text.
To use a Rollform Pipe Marker label type:
1. From the Home Page, touch Pipe Marker , then touch Create New File
.
OR
Access Pipe Marker label type according to previous procedures (page 111).
2. On the Pipe Marker Style screen, touch Rollform .
3. In the Dimensions dialog, touch the Pipe diameter: data field and enter the diameter of the
pipe to which the label will be afixed.
4. Under Tape width: touch the desired Tape Width, then touch Next .
In the Pipe contents dialog box, choose the type of material that flows through the pipe.
5. Touch the up/down arrows to view more options in the list.
6. When found, touch the desired contents option to select it, then touch Next .
