Application Label Types
BBP
®
35/37 User’s Manual 158 Rev A
CLP Arrow Pipe Marker
To create a CLP symbol or arrow pipe marker:
1. From the Home Page, touch More Label Types button , then touch CLP Pipe
Markers.
2. On the CLP Pipe Marker screen, touch Create New File .
3. On the Pipe Marker Style screen, touch Symbol or Arrow Tape .
4. In the Dimensions dialog, touch the Pipe diameter: data field and enter the diameter of the
pipe to which the label will be afixed.
5. Under Tape width: touch the desired Tape Width, then touch Next .
In the Pipe contents dialog box, choose the type of material that flows through the pipe.
6. Touch the up/down arrows to view more options in the list.
7. When found, touch the desired contents option to select it, then touch Next .
You can add a single arrow or symbol (graphic) to the pipe marker label.
8. On the Symbol Type screen, touch Arrow to add an
arrow to the label.
OR
Touch Symbol to add a graphic to the label.
