Application Label Types
BBP
®
35/37 User’s Manual 148 Rev A
You can add a single arrow or symbol (graphic) to the pipe marker label.
7. On the Symbol Type screen, touch Arrow to add an
arrow to the label.
OR
Touch Symbol to add a graphic to the label.
If selecting Symbol, the Graphics screen displays. The available graphics are divided into
categories. To change to another category:
8. Touch Change Category .
9. Under Categories, touch the up/down arrows to view more categories in the list.
10. Touch the desired category to select it, then touch OK .
11. On the Graphics screen, touch the left or right double arrows to scroll
throught the list of available graphics.
12. Touch the desired graphic in the list.
13. When ready, touch Finish .
