Braun Aesculap - Page 3

Remote in Video out
External device
(e. g. Documentation)
Video in
Direct video connection (optional)
Video cable 2
Video cable 1
External communication
interface compatible device
Interface
External communication
interface compatible device
Interface
Remote in Video out
External device
(e. g. Documentation)
Video in
Video out
External device 2
(e. g. Documentation)
Video inRemote in Video out
External device
(e. g. Documentation)
Video in
Direct video connection (option 1)
Video cable 4
Video cable 3
Video cable 2
Video cable 1
Direct video conntection (option 2)
External communication
interface compatible device
Interface
3.
1.
2.
