4-14
Confidential
(31) Remove the Pin of the Air duct from the frame. Slide the Air duct to the direction of 31b
and remove the Air duct.
Fig. 4-21
Pin
Hook
Hook
Hook
Hook
Laser unit
Air duct
31b
31a
