Brother DCP 8085DN

5-30
Confidential
9. DISASSEMBLY PROCEDURE
■ Preparation
Prior to proceeding with the disassembly procedure,
(1) Unplug
• the AC cord,
• the USB cable, if connected,
• the LAN cable, if connected.
(2) Remove
• the Paper tray,
• the Toner cartridge and Drum unit,
• the DX unit.
Fig. 5-5
DX unit
Paper tray
Drum/toner ASSY
AC cord
USB I/F cable
LAN cable
