Brother DCP 8085DN Service Manual

2-31
Confidential
3.6 Sensors position
Sensor name Type Located on Function
Regist front sensor Photo sensor High-voltage PS PCB
Detect the paper top
position or absence of
paper.
Regist rear sensor Photo sensor High-voltage PS PCB
Control the first print
position on the paper.
Paper eject sensor Photo sensor Relay rear PCB
Detect whether the paper
is ejected.
New toner sensor Photo sensor Relay front PCB
Detect whether a new
toner cartridge is installed.
Detect a new toner
cartridge type.
Toner LED PCB
(Light emission)
Photo sensor Frame R
Detect whether the toner
cartridge which contains
enough toner.
Toner sensor PCB
(Light reception)
Photo sensor Frame L
Front cover sensor
Mechanical
switch
Frame L
Detect the opening and
closing of the front cover.
PE sensor Photo sensor PE EG sensor ASSY
Detect the absence of the
paper in each paper tray.
Edge sensor Photo sensor PE EG sensor ASSY
Detect the absence of
each paper tray.
Detect whether the paper
is sent from the tray.
MP PE sensor Photo sensor MP PE sensor ASSY
Detect the absence of the
paper in the MP tray.
DX tray sensor
Mechanical
switch
Relay rear PCB
Detect the opening and
closing of the back cover.
Detect the absence of the
DX unit.
Document front
sensor 1
Photo sensor ADF
Detect the absence of the
paper in the ADF unit.
Document front
sensor 2
Photo sensor ADF
Detect whether the paper
is drawn.
Document rear
sensor
Photo sensor ADF
Detect the length of the
paper.
Switch back sensor Photo sensor ADF
When the duplex printing,
detect the timing of
reversing of the paper.
Document cover
sensor
Photo sensor ADF
Detect the opening and
closing of the document
cover.
HP sensor Photo sensor Scanner unit ASSY
Detect the home position
of the CCD unit.

Brother DCP 8085DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	CIFS, E-mail, FTP, Image, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	TFT
Market positioning	Business
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Scan
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP professional x64 Edition, Vista Mac OS X 10.3.9 + Linux
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, Web Services (Print), CIFS Client, SNTP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, Web Services (Print), CIFS Client, SNTP
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	1
Bundled software	Brother MFL-pro suite in Windows: BrotherControlCentre 3 Scansoft Paperport 11SE + OCR, Macintosh:BrotherControlCentre 2 Newsoft Presto! Page manager 7
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	680 W
Package weight	21800 g
Maximum duty cycle	30000 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
