Brother DCP 8085DN Service Manual

7-28
Confidential
4.16 Acquisition of White Level Data and CCD Scanner Area Setting
(Function code 55)
<Function>
This function allows the machine to obtain white level data for the CCD scanner and save it
together with the CCD scanner area into the EEPROM on the main PCB.
<Operating Procedure>
(1) Press the [5] key twice in the initial stage of the maintenance mode.
The “SCANNER AREA SET” will appear on the LCD.
(2) When setting of the scanner area is completed, a 4-digit number will appear on the LCD.
(e.g., 4723)
* If you press the [Stop/Exit] button at this point, the machine will beep for one second
and return to the initial stage of the maintenance mode.
Enter the input data value of a 5-digit number based on the 4-digit number to be
displayed referring to the table below. (e.g., 4723
→ 47247)
(3) The machine saves the magnification compensation setting value into the EEPROM,
and then it beeps for one second and returns to the initial stage of the maintenance
mode.
Maintenance mode 55 required input data Input data
1 4610 --- 4619 → 46156
2 4620 --- 4629
→ 46257
3 4630 --- 4639
→ 46358
4 4640 --- 4649
→ 46459
5 4650 --- 4659
→ 46550
6 4660 --- 4669
→ 46651
7 4670 --- 4679
→ 46752
8 4680 --- 4689
→ 46853
9 4690 --- 4699
→ 46954
10 4700 --- 4709
→ 47056
11 4710 --- 4719
→ 47157
12 4720 --- 4729
→ 47247
13 4730 --- 4739
→ 47359
14 4740 --- 4749
→ 47450
15 4750 --- 4759
→ 47551
16 4760 --- 4769
→ 47652
17 4770 --- 4779
→ 47753
18 4780 --- 4789
→ 47854
19 4790 --- 4799
→ 47955
20 4800 --- 4809
→ 48057
21 4810 --- 4819
→ 48158
22 4820 --- 4829
→ 48259
23 4830 --- 4838
→ 48350
