4.9 ROM Version Check (Function code 25)
<Function>
This function allows you to check the management information of the software programs
such as version information, check sum.
<Operating Procedure>
(1) Press the [2] key and [5] key in this order in the initial stage of the maintenance mode.
The machine displays each of terms described below on the LCD.
(2) Press the [ ] or [ ] button to check the next term.
*1 In the case of the model without Demo data, the “D·········· : ····” displayed on the LCD.
*2 The parformance of ROM check sum pushes the [OK] button during the “ROM
Check Sum” displayed on the LCD. Calculate the check sum information and display
the “ROM Check Sum OK” if right, and display the “ROM Check Sum NG” if different.
• How to display the check sum information
Terms displayed with “*” have the check sum information as well. Press the [OK]
button when its version information is displayed on the LCD. Press the [OK] button
again to go back to the version information display. Press the [ ] or [ ] buttons to
check the next term.
(3) To terminate this operation, press the [Stop/Exit] button. The machine beeps for one
second and returns to the initial stage of the maintenance mode.
LCD Description
TOTAL: Ver A* Main firmware version information (Revision information)
PCL : Ver1.00* Sub firmware (PCL/PS) version information (ROM size)
NET : Ver1.00 Network version information
PANEL : A08103015 Panel firmware version information
i0802312359: 1234*
B0808071049:5708* Boot program creation date & check sum information
U0812271600:7B0A* Main firmware creation date & check sum information
D0812312359: 1234*
*1
Demo program creation date & check sum information
P0812271602:BD40* Sub firmware (PCL/PS) creation date & check sum information
ROM Check Sum
*2
Calculate the check sum information of the main and PCL and
display the “OK” if right.
Note:
• If you press the [OK] button when each version information of Engine,
Network and Panel is displayed on the LCD, you cannot check the check sum
information.

Brother DCP 8085DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	CIFS, E-mail, FTP, Image, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	TFT
Market positioning	Business
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Scan
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP professional x64 Edition, Vista Mac OS X 10.3.9 + Linux
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, Web Services (Print), CIFS Client, SNTP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, Web Services (Print), CIFS Client, SNTP
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	1
Bundled software	Brother MFL-pro suite in Windows: BrotherControlCentre 3 Scansoft Paperport 11SE + OCR, Macintosh:BrotherControlCentre 2 Newsoft Presto! Page manager 7
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	680 W
Package weight	21800 g
Maximum duty cycle	30000 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
