5-119
Confidential
9.77 Gear 17/20/23
(1) Remove the Gear 23.
Fig. 5-157
(2) Remove the Gear 20.
Fig. 5-158
Frame L
Hook
Gear 23
Frame L
Gear 20
Hook
