Brother DCP 8085DN Service Manual

1-20
Confidential
2.10 Fax
Model
DCP
8080DN
DCP
8085DN
MFC
8480DN
MFC
8880DN
MFC
8890DW
Modem Speed No 33.600bps
Transmission Speed No Approx. 2sec.
(Brother#1 Std resolution,JBIG)
ITU-T Group No Super G3
Coding Method No MH / MR / MMR / JBIG
Color FAX No
Fax/Tel Switch No Yes
Super Fine No Yes (TX & RX)
Gray Scale No 8bit/256
Contrast No Yes (Auto/Light/Dark)
Smoothing No
Dual Access No Yes
Enhanced Remote
Activate
No Yes
Station ID No Yes (20digits / 20characters)
Remote Maintenance No
Remote Access No Yes
Fax Retrieval No Yes
Paging No Yes (US / Canada Only)
Internet FAX
(ITU T.37 simple mode)
No Yes
Delayed Timer No Yes (up to 50)
Polled Sending No Yes (EUR Secure Polling)
Multi Transmission No
Multi Resolution
Transmission
No
Next-Fax Reservation No
Call Reservation Over
Auto/Manual TX
No
Batch Transmission No Yes
Quick-Scan
(Memory transmission)
Approx. 2 sec./page (A4 standard)
Memory Transmission
(ITU-T Chart)
up to 500 pages (ITU-T Test Chart,
Standard Resolution, JBIG)
up to 600 pages (Brother #1Chart,
Standard Resolution, JBIG)
ECM
(Error Correction Mode)
Yes
Error Re-Transmission No Yes
Broadcasting No Yes (390 locations)
Manual Broadcasting No Yes (50 locations )
Fax Forwarding No Yes

Brother DCP 8085DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	CIFS, E-mail, FTP, Image, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	TFT
Market positioning	Business
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Scan
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP professional x64 Edition, Vista Mac OS X 10.3.9 + Linux
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, Web Services (Print), CIFS Client, SNTP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, Web Services (Print), CIFS Client, SNTP
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	1
Bundled software	Brother MFL-pro suite in Windows: BrotherControlCentre 3 Scansoft Paperport 11SE + OCR, Macintosh:BrotherControlCentre 2 Newsoft Presto! Page manager 7
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	680 W
Package weight	21800 g
Maximum duty cycle	30000 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
