5-110
Confidential
9.67 Relay Rear PCB ASSY/Connector
(1) Remove the Relay rear PCB ASSY (Include the DX sensor).
Fig. 5-140
Hooks
Hooks
Hook
Relay rear PCB ASSY
Frame L
DX sensor
