5-155
Confidential
10.3 LT Rear Cover
(1) Remove the two cup S M3x6 Taptite SR screws.
(2) Remove the LT rear cover.
Fig. 5-217
LT rear cover
Taptite, cup S M3x6 SR
<Back side>
