9.93 PE EG Sensor ASSY
(1) Remove the three bind B M4x12 Taptite screws, and remove the MP frame.
Fig. 5-207
Paper feed frame
Frame R
MP frame
Taptite bind B M4x12
Taptite bind B M4x12
Taptite, bind B M4x12
