Brother DCP 8085DN

5-6
Confidential
FB FG harness Taptite cup S M3x6 1 0.8±0.1 (8±1)
Drive plate ASSY Taptite B M3x8 4 0.5±0.1 (5±1)
Scanner motor FB
Screw, pan (S/P washer)
M3X6
2 0.7±0.1 (7±1)
Pulley ASSY Taptite B M3x6 2 0.4±0.05 (4±0.5)
Panel unit generic Taptite cup B M4x12 4 0.7±0.1 (7±1)
Panel cover generic Taptite cup B M3x10 4 0.5±0.1 (5±1)
NCU FG harness ASSY
Screw, pan (S/P washer)
M3.5X7.5 SR
2 0.4±0.05 (4±0.5)
NCU shield plate Taptite bind B M4x12 2
NCU shield cover
Screw, pan (S/P washer)
M3.5X6
1
NCU PCB ASSY Taptite cup S M3x6 2
Speaker hold spring Taptite bind B M4x12 1 0.8±0.1 (8±1)
Driver PCB shield
Taptite cup B M3x8 2 0.4±0.05 (4±0.5)
Taptite cup S M3x6 SR 1 0.75±0.1 (7.5±1)
USB HOST FG harness ASSY Taptite bind B M4x12 1
USB PCB holder Taptite bind B M4x12 1
USB HOST PCB Taptite cup S M3x6 SR 1
Side cover R Taptite bind B M4x12 2 0.7±0.1 (7±1)
Joint cover ASSY Taptite bind B M4x12 4 0.8±0.1 (8±1)
Main PCB
Taptite cup S M3x6 SR 4 0.75±0.1 (7.5±1)
Set screw 2 0.5±0.1 (5±1)
Gear plate calking ASSY
Taptite bind B M4x12 8 0.9±0.05 (9±0.5)
Taptite cup S M3x6 SR 1 0.7±0.1 (7±1)
Main motor ASSY Taptite cup S M3x6 4 0.7±0.1 (7±1)
Plate Taptite bind B M4x12 2 0.8±0.1 (8±1)
Main shield plate ASSY
Taptite bind B M4x12 3 0.9±0.1 (9±1)
Taptite cup S M3x6 1 0.7±0.1 (7±1)
MP solenoid ASSY Taptite bind B M3x10 1 0.5±0.05 (5±0.5)
Spring Taptite cup B M3x8 1 0.4±0.1 (4±1)
T1 solenoid ASSY Taptite bind B M3x10 1 0.5±0.05 (5±0.5)
Register solenoid ASSY Taptite bind B M3x10 1 0.5±0.05 (5±0.5)
Ejector solenoid ASSY Taptite bind B M3x10 1 0.5±0.1 (5±1)
New toner actuator Taptite cup B M2x6 1
0.13±0.03
(1.3±0.3)
Laser unit Taptite cup S M3x6 5 0.7±0.1 (7±1)
Base plate LV
Taptite bind B M4x12 5 0.8±0.1 (8±1)
Screw, pan (S/P washer)
M3.5X7.5 SR
1 0.4±0.05 (4±0.5)
LV insulation sheet Taptite bind B M4x12 1 0.8±0.1 (8±1)
SW holder ASSY Taptite bind B M4x12 1 1.0±0.1 (10±1)
Location of screw Screw type Q’ty
Tightening torque
N m (kgf · cm)
