Brother DCP 8085DN

5-20
Confidential
16
ADF unit (Document front sensor 1, Document front sensor 2)
Document front sensor 1
Document front sensor 2
Document front
sensor 1
Document front
sensor 2
Document front
sensor 2
Document front
sensor 1
Actuator front 1
Paper feed chute ASSY
Document front sensor 2
Hole "C"
Hole "C"
Hole
Hook
Hooks
Hook
Hook
Hook
Hook
Hooks
Hook
Paper feed chute ASSY
ADF Relay PCB
Drive frame sub ASSY DX
Motor frame
ASSY
Motor frame ASSY
ADF Relay PCB
<A view>
<A view>
<B view>
<B view>
