Brother DCP 8085DN Service Manual

7-33
Confidential
*
1
Not indicated.
*
2
Some margin of error must be taken into consideration because coverage for the printable
area of A4-size paper is calculated using video signals.
TTLCOPY: Number of copies made
TTLPCPT: Number of PC prints made
TTLFAX: Number of FAX outputs made
TR1_PG: Number of pages picked up from the T1.
TR2_PG: Number of pages picked up from the LT.
MP_PG: Number of pages picked up from the MP.
DX_PG: Number of pages picked up from the DX.
A4+LTR: Number of A4/Letter size sheets picked up.
LG+A4L: Number of LEGAL/A4 LONG size sheets picked up.
B5+EXE: Number of B5/Executive size sheets picked up.
ENVLOP: Number of envelopes picked up.
A5: Number of A5 size sheets picked up.
OTHER: Number of other-size sheets picked up.
PLTNRE: Number of Plain/Thin/Recycled sheets made.
TRANSP: Number of Transparency mode.
TKTRBD: Number of Thick/Thicker/Bond made.
ENVTYP: Number of envelopes picked up.
HAGAKI: Number of HAGAKI
LABEL: Number of label
ADSX_PG: Number of pages scanned with the ADF. (Simplex scanning)
ADDX_PG: Number of pages scanned with the ADF. (Duplex scanning)
FB_PG: Number of pages scanned with the FB unit.
KDEV_BIAS: Black developing bias voltage
POWER: Total energization time
PWRCNT: Number of power ON
TTL_JAM: Total number of jams
TR1_JAM: Number of jams that occurred at the T1.
TR2_JAM: Number of jams that occurred at the LT.
MP_JAM: Number of jams that occurred at the MP.
DX_JAM: Number of jams that occurred at the DX.
IN_JAM: Number of jams that occurred inside the machine.
RE_JAM: Number of jams that occurred at the ejecting.
ADSX_JAM: Number of jams occurred in simplex scanning with the ADF.
ADDX_JAM: Number of jams occurred in duplex scanning with the ADF.
HODN_ER: Number of electric discharge error.
FUSR_ER: Number of fuser error.
MTLK_ER: Number of motor lock error.
MACHINE ERR_01 to 10 Last machine error code 01 to 10
COMERR1 to 3 Last communication error code 1 to 3

Brother DCP 8085DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	CIFS, E-mail, FTP, Image, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	TFT
Market positioning	Business
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Scan
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP professional x64 Edition, Vista Mac OS X 10.3.9 + Linux
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, Web Services (Print), CIFS Client, SNTP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, Web Services (Print), CIFS Client, SNTP
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	1
Bundled software	Brother MFL-pro suite in Windows: BrotherControlCentre 3 Scansoft Paperport 11SE + OCR, Macintosh:BrotherControlCentre 2 Newsoft Presto! Page manager 7
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	680 W
Package weight	21800 g
Maximum duty cycle	30000 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
