App. 1-20
Confidential
<WSW14>
Selectors 1 through 4: Frequency band selection for incoming calling signal (CI)
These selectors are used to select the frequency band of CI for activating the AUTO ANS
facility.
In the French models, if the user sets the PBX to OFF from the control panel, the setting
made by selectors 1 and 2 will take no effect and the frequency's lower limit will be fixed to
32 Hz. (Even if the setting made by these selectors does not apply, it will be printed on the
configuration list.)
Selectors 5 through 8: No. of rings in AUTO ANS mode
These selectors set the number of rings to initiate the AUTO ANS facility.
Selector No. Function Setting and Specifications
1
2
Frequency band selection
(lower limit) for incoming calling
signal (CI)
No. 1 2
0 0: 13 Hz
0 1: 15 Hz
1 0: 23 Hz
1 1: 20 Hz
3
4
Frequency band selection
(upper limit) for incoming calling
signal (CI)
No. 3 4
0 0: 30 Hz
0 1: 55 Hz
1 0: 70 Hz
1 1: 200 Hz
5
I
8
No. of rings in AUTO ANS mode
No. 5 6 7 8
0000: Fixed to once
0001: 1 to 6 times
0010: 1 to 8 times
0011: 2 to 8 times
0100: 1 to 2 times
0101: 1 to 3 times
0110: 1 to 4 times
0111: 1 to 5 times
1000: 2 to 3 times
1001: 2 to 4 times
1010: 2 to 5 times
1011: 2 to 6 times
1 1 0 0: 1 to 10 times
1 1 0 1: 2 to 10 times
1110: 3 to 5 times
1 1 1 1: 4 to 10 times
