Brother DCP 8085DN

App. 1-30
Confidential
<WSW24>
• Selectors 3 and 4:Time length from CML ON to start of pseudo ring backtone
transmission
These selectors set the length of time from CML-ON up to the start of pseudo ring
backtone transmission.
In models with OGM facilities, the settings made by these selectors also apply to the length
of time from CML-ON up to the start of OGM transmission.
Selector No. Function Setting and Specifications
1
2
Maximum OGM recording time
(Not used.)
No. 1 2
0 0: 15 sec.
0 1: 20 sec.
1 0: 30 sec.
1 1: 50 sec.
3
4
Time length from CML ON to
start of pseudo ring backtone
transmission
No. 3 4
00: 4 sec.
01: 3 sec.
10: 2 sec.
11: 1 sec.
5
I
8
Attenuator for playback of ICM/
OGM to the line
(Not used.)
0: 0 dB 1: 8 dB
0: 0 dB 1: 4 dB
0: 0 dB 1: 2 dB
0: 0 dB 1: 1 dB
