Brother DCP 8085DN Service Manual

App. 1-32
Confidential
<WSW26>
• Selector 3: Dialing during document reading into the temporary memory in in-
memory message transmission
If this selector is set to "0," the machine waits for document reading into the memory to
complete and then starts dialing. This enables the machine to list the total number of
pages in the header of the facsimile message.
• Selectors 4 and 5:No. of CNG cycles to be detected (when the line is connected via
the external telephone except in the external TAD mode or via the
built-in telephone)
The machine interprets a CNG as an effective signal if it detects the CNG by the number of
cycles specified by these selectors when the line is connected via the external telephone
except in the external TAD mode or via the built-in telephone.
Selector No. Function Setting and Specifications
1
2
Not used.
3
Dialing during document reading
into the temporary memory in in-
memory message transmission
0: Disable 1: Enable
4
5
No. of CNG cycles to be detected
(when the line is connected via
the external telephone except in
the external TAD mode or via the
built-in telephone)
In the case of Selector 3=0 in WSW54.
No. 4 5
00: 0.5 (A)
01: 1 (B)
10: 1.5 (C)
11: 2 (D)
In the case of Selector 3=1 in WSW54.
No. 4 5
00: 2.5 (A)
01: 3 (B)
10: 3.5 (C)
11: 4 (D)
6
7
No. of CNG cycles to be detected
(when the line is connected via
the external telephone in the
external TAD mode, via the built-
in telephone in the TAD mode, or
via the machine in the automatic
reception of the F/T mode)
In the case of Selector 6=0 in WSW58.
No. 6 7
00: 0.5 (A)
01: 1 (B)
10: 1.5 (C)
11: 2 (D)
In the case of Selector 6=1 in WSW58.
No. 6 7
00: 2.5 (A)
01: 3 (B)
10: 3.5 (C)
11: 4 (D)
8 Not used.

Brother DCP 8085DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	CIFS, E-mail, FTP, Image, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	TFT
Market positioning	Business
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Scan
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP professional x64 Edition, Vista Mac OS X 10.3.9 + Linux
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, Web Services (Print), CIFS Client, SNTP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, Web Services (Print), CIFS Client, SNTP
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	1
Bundled software	Brother MFL-pro suite in Windows: BrotherControlCentre 3 Scansoft Paperport 11SE + OCR, Macintosh:BrotherControlCentre 2 Newsoft Presto! Page manager 7
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	680 W
Package weight	21800 g
Maximum duty cycle	30000 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
