Brother DCP 8085DN Service Manual

App. 1-63
Confidential
<WSW56>
• Selector 3: "Last Job Reprint" function setting
Setting this selector to "0" makes the machine not to reprint the "Last Job Print" data such
as confidential document in order to prevent the misuse.
• Selector 4: Wireless LAN function
To disable the wireless LAN (WLAN) functions, set this selector to "1" and turn the machine
power off and then on.
• Selector 5: Switching of the echo suppression improvement during calling
To suppress the echo during calling, set this selector to "0". The default value is "0:Enable".
• Selector 6: Switching of the display for the coverage of toner cartridge
This selector specifies the display for the coverage of toner cartridge. Setting this selector
to "0", the machine displays the coverage only for the current toner cartridge. If this selector
sets to "1", the machine displays the coverage for all toner cartridge which had been
consumed.
• Selector 7: PCL emulation function setting
This selector is applicable to models equipped without PCL emulation.
• Selector 8: Switching of the CPU sleep mode
This selector specifies the CPU sleep mode ON or OFF.
Selector No. Function Setting and Specifications
1
PS emulation function setting
(Not used.)
0: Invalid 1: Valid
2 Switching of the PPT setting 0: Invalid 1: Valid
3
"Last Job Reprint" function
setting
0: Invalid 1: Valid
4 Wireless LAN function
0: Enable(default)
1: Disable
5
Switching of the echo
suppression improvement
during calling
0: Enable 1: Disable
6
Switching of the display for the
coverage of toner cartridge
0: The coverage only for the current
toner cartridge
1: The coverage for all toner
cartridges which had been
consumed
7 PCL emulation function setting 0: Invalid 1: Valid
8
Switching of the CPU sleep
mode
0: Invalid 1: Valid

Brother DCP 8085DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	CIFS, E-mail, FTP, Image, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	TFT
Market positioning	Business
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Scan
Compatible operating systems	Windows 2000 Professional, XP Home Edition, XP Professional Edition, XP professional x64 Edition, Vista Mac OS X 10.3.9 + Linux
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, Web Services (Print), CIFS Client, SNTP
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, Web Services (Print), CIFS Client, SNTP
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	1
Bundled software	Brother MFL-pro suite in Windows: BrotherControlCentre 3 Scansoft Paperport 11SE + OCR, Macintosh:BrotherControlCentre 2 Newsoft Presto! Page manager 7
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	680 W
Package weight	21800 g
Maximum duty cycle	30000 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
