3-103
Confidential
(3) Release the Hook to remove the Registration gear 25 terminal, the two Feeder gear 17
terminals and the Bush 6.
Fig. 3-107
Registration gear 25 terminal
Bush 6
Feeder gear 17 terminal
Hook
3a
3b
3c
3b
3c
3d
3a
<Left side>
