5-11
Confidential
DCP7045N/7040/7030
(1) Press the or button several times. The machine displays the "MAINTENANCE 10"
on the LCD and becomes ready to accept a firmware switch number.
(2) Press the or button several times. The machine displays that the desired number
from the firmware switch numbers (01 through 63), and the press the OK key.
The following appears on the LCD:
(3) If press the button, it is changed to "1". And press the button, it is changed to "0" in
the state that the cursor is displayed the selector 1. And then the cursor moves to the
selector 2. Change the firmware switch in the arbitrary value by this method.
(4) If enter all selectors, press the OK button. This operation saves the newly entered
selector values onto the EEPROM and readies the machine for accepting a firmware
switch number.
(5) Repeat steps (2) through (4) until the modification for the desired firmware switches is
completed.
(6) Press the Stop/Exit button to return the machine to the initial stage of the maintenance
mode.
Note :
• To cancel this operation and return the machine to the initial stage of the maintenance
mode during the above procedure, press the Stop/Exit button.
■ Details of Firmware Switches
The details of the firmware switches are described in APPENDIX 1 in which the user-
accessible selectors of the firmware switches are shaded.
Selector 1 Selector 8
WSWXX = 0 0 0 0 0 0 0 0
