<WSW54>
Note:
• Selectors 1 and 2 are applicable only to models equipped with PictBridge.
• Selector 4 is applicable only to models equipped with cordless handset(s).
• Selectors 5 through 7 are applicable only to models designed for the UK market.
• Selector 8 is applicable only to models designed for the Chinese market.
• Selector 1 and 2: PictBridge command delay time (Not used)
These selectors specify the PictBridge command delay time that applies when the machine
responds to the digital camera connected via PictBridge during negotiation. If the machine
fails to receive data from the digital camera, change the delay time.
• Selector 3: More CNG detection cycles in user-friendly reception
If CNG detection fails even after adjustment of selectors 4 and 5 on WSW26, try adding 2
more cycles to the permitted number of CNG detection cycles.
• Selector 4: Cordless handset ID recovery (Not used)
When this function becomes operative, if the cordless handset ID number registered on the
main board does not match that registered on the cordless board, the cordless handset ID
number registered on the main board will be automatically written onto the cordless board.
• Selectors 5 and 6: Caller ID tone alert detection time length
In the event of a false detection of a caller ID tone alert, adjust the detection time length.
• Selector 7: Caller ID mild pulse transmission (Not used.)
If a caller ID (number display) cannot be displayed due to mild pulses transmitted after
detection of tone alert, use this selector so as to make it impossible to transmit mild pulses.
Selector No. Function Setting and Specifications
1
2
PictBridge command delay time
(Not used.)
No. 1 2
0 0: 100 ms (default)
01: 0 ms
1 0: 50 ms
1 1: 200 ms
3
More CNG detection cycles in
user-friendly reception
0: No 1: 2 more cycles
4
Cordless handset ID recovery
future (Not used.)
0: Valid 1: Invalid
5
6
Caller ID tone alert detection
time length
No. 5 6
0 0: 50 ms (default)
0 1: 60 ms
1 0: 70 ms
1 1: 80 ms
7
Caller ID mild pulse
transmission (Not used.)
0: Yes 1: No
(default)
8
Switching between DTMF and
FSK for caller ID reception (Not
used.)
0: DTMF 1: FSK
(default)
