Brother MFC-7450

3-4
Confidential
INLET HARNESS ASSY Screw pan (S/P washer)
M3.5x6
10.5±0.05 (5±0.5)
Taptite flat B M3x10 2
0.45 ± 0.05 (4.5 ± 0.5)
LVPS PCB UNIT Taptite cup S M3x6 SR 2 0.5±0.05 (5±0.5)
LV SHIELD PLATE 2 Taptite bind B M4x12 2 0.8±0.1 (8±1)
Back Side Taptite cup S M3x6 SR 1 0.6±0.1 (6±1)
Front chute ground plate
side
Taptite cup S M3x6 SR 1 0.5±0.05 (5±0.5)
ACTUATOR HOLDER ASSY Taptite bind B M3x10 2 0.5±0.1 (5±1)
REGISTRATION FRONT SENSOR
PCB ASSY
Taptite bind B M3x10 1 0.5±0.1 (5±1)
REAR ACTUATOR HOLDER ASSY Taptite bind B M3x10 2 0.5±0.1 (5±1)
REGISTRATION REAR SENSOR
PCB ASSY
Taptite bind B M3x10 1 0.5±0.1 (5±1)
UNDER FG WIRE Taptite bind B M4x12 1 0.8±0.1 (8±1)
Taptite cup S M3x6 SR 1 0.8±0.05 (8±0.5)
DRIVE SUB ASSY Taptite cup S M3x6 SR 1 0.6±0.1 (6±1)
Taptite bind B M4x12 9 0.8±0.1 (8±1)
TONER SENSOR HARNESS ASSY Taptite bind B M3x10 1 0.5±0.1 (5±1)
REGISTRATION SOLENOID Taptite bind B M3x10 1 0.5±0.1 (5±1)
T1 SOLENOID Taptite bind B M3x10 1 0.5±0.1 (5±1)
FU FRONT PAPER GUIDE Taptite bind B M3x10 3 0.5±0.1 (5±1)
CHUTE GROUND PLATE Taptite cup S M3x6 SR 2 0.6±0.1 (6±1)
MAIN SHIELD PLATE Taptite bind B M4x12 3 0.8±0.1 (8±1)
MAIN FRAME L ASSY Taptite bind B M4x12 4 0.8±0.1 (8±1)
Taptite cup S M3x6 SR 2 0.7±0.1 (7±1)
Location of screw Screw type Q’ty
Tightening torque
N m (kgf · cm)
