Scanner
®
2000 microEFM Section 1
LCD / keypad
CSA-approved
3/4 in. to 1 in. adapter
CSA-approved
union (connects directly
to the turbine meter)
LCD / keypad
Mount for pole-mount hardware
Ground screw
Conduit plug
Enclosure lid
(remove to access keypad)
Figure 1.2—Scanner 2000 microEFM for direct connection to a turbine meter (CSA-approved)
Figure 1.3—Scanner 2000 microEFM for direct connection to a Barton 7000 Series turbine meter (ATEX-
approved)
