Cameron Scanner 2000 microEFM User Manual

D-48
Appendix D Scanner
®
2000 microEFM
Units of Measurement
Value Units Scale Offset
1502 A 0.0010000000 0.00
1601 cP 1.0000000000 0.00
1602 lbm/ft.sec 1488.1159420290 0.00
Log Capacity
Log Type Capacity
Interval Logs (without expansion board) 2304
Interval Logs (with expansion board) 6392
Daily Logs 768
Event Logs 1152
Enron Log Data
The Scanner 2000 provides Enron Modbus® compliant downloads. For detailed instructions on downloading
interval, daily and event data, refer to SpecicationsandRequirementsforanElectronicFlowMeasurement
RemoteTerminalUnitforEnronCorp. If an Enron host is not available or is too cumbersome or inefcient
for the host system, there are other methods that are available to retrieve the log data from the instrument.
Contact Cameron technical support for details.
The following registers are used for interval, daily and event log registers. Interval and daily records contain
16 user-congurable values. For details on the archive conguration, see Section 3 of the ModWorX Pro
Software User Manual. All of the Enron registers have an access type of Read Only (RO).
Enron Registers
Register Description Data Type
32 Enron Modbus® Event Log Register Refer to Enron Event Record Format
700 Enron Modbus® Interval Log Refer to Enron Interval/Daily Record Format
701 Enron Modbus® Daily Log Refer to Enron Interval/Daily Record Format
7000
Interval Pointer
[1 to 2304, standard Scanner 2000]
[1 to 6392, Scanner 2000 plus
expansion board]
FP32
7001
Daily Pointer
[1 to 768]
FP32
7002
Event Counter
[1 to 2304]
FP32
