Cameron Scanner 2000 microEFM User Manual

D-49
Scanner
®
2000 microEFM Appendix D
Enron Interval/Daily Record Format
The interval and daily record contents are user-congurable. The following table shows the default values.
For more information, see Section 3 of the ModWorX Pro Software User Manual.
Parameter Data Type
Date (MMDDYY) FP32
Time (HH:MM:SS) FP32
FR1 Previous Volume (base units) FP32
FR1 Previous Mass (base units) FP32
FR1 Previous Energy (base units) FP32
Differential Pressure Previous Average (InH2O) FP32
Static Pressure Previous Average
(PSIA default, can be PSIG)
FP32
Process Temperature Previous Average (DegF) FP32
FR1 Previous Run Time (seconds of ow) FP32
Turbine 1 Previous Volume (base units) FP32
Turbine 1 Previous Run Time (seconds of ow) FP32
<Parameter 12> FP32
<Parameter 13> FP32
<Parameter 14> FP32
<Parameter 15> FP32
<Parameter 16> FP32
Enron Event Record Format
Parameter Data Type
Status U16
Address U16
Time (HH:MM:SS) FP32
Date (MMDDYY) FP32
As-Found FP32
As-Left FP32
The status parameter in the event record can be decoded with the following table.
Alarm Decoding
Description Bit
<Unassigned> 0-8
User Change/Event 9
Low Low Alarm 10
Low Alarm 11
Hi Alarm 12
Hi Hi Alarm 13
<Unassigned> 14
Alarm Set/Reset (1=Set, 0=Reset) 15
