Flow Rate Calculation
6 ISA Nozzle (FUTURE)
7 Long Radius Nozzle (FUTURE)
8 Averaging Pitot Tube (Annubar®)
Fluid Property Register
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
HV SG V Isen LiqDC GPA HVRef Fluid Property Calc
HV - Heating Value Selection
0 Calculated
1 Manual Entry
SG - Specic Gravity Selection
0 Calculated
1 Manual Entry
V - Viscosity Selection
0 Calculated
1 Manual Entry
Isen - Isentropic Exponent Selection
0 Calculated
1 Manual Entry
LiqDC – Liquid Density Control
0 For Liquids: Register 3057 contains the owing density
For NGas: Register 3057 contains the base liquid oil density
1 For Liquids: Register 3057 contains the coefcient of thermal
expansion
For NGas: Register 3057 contains the owing liquid oil
density
GPA - GPA Table Selection
0 Use 2008 Table
1 Use 1996 Table
HVRef - Heating Value Reference
0 US (AGA) – 14.73 psi, 60 Deg F
1 Canada, UK – 103.208 kPa, 15 Deg C
2 Brazil (FUTURE)
3 France (FUTURE)
Fluid Property Calculation
0 AGA-8 Detail
1 AGA-8 Gross
2 (FUTURE)
3 IF-97 (STEAM ONLY)
4 IF-97/James - (STEAM ONLY)
5-15 (FUTURE)
16 Generic Liquid (API 2145 Table 6C)
