Cameron Scanner 2000 microEFM User Manual

D-16
Appendix D Scanner
®
2000 microEFM
Analog Input 1 Conguration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2500 9C4 A1 - Units U16 R/W 0
2501 9C5 A1 - Time Base U16 R/W 0
2502 9C6 A1 - Sampling Period U16 R/W 1
2503 9C7 A1 - Dampening Factor U16 R/W 0
2504 9C8 A1 - Input Conguration U16 R/W 0
2505 9C9 A1 - Override Enable U16 R/W 0
2506 9CA A1 - Override Value FP R/W 0.00
2508 9CC A1 - Fail Value FP R/W 0.00
2510 9CE A1 - Low Input Cutoff FP R/W 2.00
2512 9D0 A1 - Low Flow Cutoff FP R/W 0.00
2514 9D2 A1 - Sensor Range Low FP RO 0.00
2516 9D4 A1 - Sensor Range High FP RO 0
2518 9D6 A1 - Units Scale Factor FP R/W 1
2520 9D8 A1 - Units Offset Factor FP R/W 0
2522 9DA A1 - Unit Description 1 LCD R/W —
2523 9DB A1 - Unit Description 2 LCD R/W —
2524 9DC A1 - Unit Description 3 LCD R/W —
Analog Input 1 Calibration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2530 9E2 A1 - Calibration Type
1
U16 R/W 0
2531 9E3 A1 - Nominal Value FP R/W —
2533 9E5 A1 - Calibration Absolute Offset FP R/W 0.00
2535 9E7 A1 - Calibration Actual 1 FP R/W 0.00
2537 9E9 A1 - Calibration Actual 2 FP R/W 0.00
2539 9EB A1 - Calibration Actual 3 FP R/W 0.00
2541 9ED A1 - Calibration Actual 4 FP R/W 0.00
2543 9EF A1 - Calibration Actual 5 FP R/W 0.00
2545 9F1 A1 - Calibration Actual 6 FP R/W 0.00
2547 9F3 A1 - Calibration Actual 7 FP R/W 0.00
2549 9F5 A1 - Calibration Actual 8 FP R/W 0.00
2551 9F7 A1 - Calibration Actual 9 FP R/W 0.00
2553 9F9 A1 - Calibration Actual 10 FP R/W 0.00
2555 9FB A1 - Calibration Actual 11 FP R/W 0.00
2557 9FD A1 - Calibration Actual 12 FP R/W 0.00
2559 9FF A1 - Calibration Measured 1 FP R/W 0.00
2561 A01 A1 - Calibration Measured 2 FP R/W 0.00
2563 A03 A1 - Calibration Measured 3 FP R/W 0.00
2565 A05 A1 - Calibration Measured 4 FP R/W 0.00
