Cameron Scanner 2000 microEFM User Manual

D-18
Appendix D Scanner
®
2000 microEFM
Analog Input 2 Calibration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2639 A4F A2 - Calibration Actual 3 FP R/W 0.00
2641 A51 A2 - Calibration Actual 4 FP R/W 0.00
2643 A53 A2 - Calibration Actual 5 FP R/W 0.00
2645 A55 A2 - Calibration Actual 6 FP R/W 0.00
2647 A57 A2 - Calibration Actual 7 FP R/W 0.00
2649 A59 A2 - Calibration Actual 8 FP R/W 0.00
2651 A5B A2 - Calibration Actual 9 FP R/W 0.00
2653 A5D A2 - Calibration Actual 10 FP R/W 0.00
2655 A5F A2 - Calibration Actual 11 FP R/W 0.00
2657 A61 A2 - Calibration Actual 12 FP R/W 0.00
2659 A63 A2 - Calibration Measured 1 FP R/W 0.00
2661 A65 A2 - Calibration Measured 2 FP R/W 0.00
2663 A67 A2 - Calibration Measured 3 FP R/W 0.00
2665 A69 A2 - Calibration Measured 4 FP R/W 0.00
2667 A6B A2 - Calibration Measured 5 FP R/W 0.00
2669 A6D A2 - Calibration Measured 6 FP R/W 0.00
2671 A6F A2 - Calibration Measured 7 FP R/W 0.00
2673 A71 A2 - Calibration Measured 8 FP R/W 0.00
2675 A73 A2 - Calibration Measured 9 FP R/W 0.00
2677 A75 A2 - Calibration Measured 10 FP R/W 0.00
2679 A77 A2 - Calibration Measured 11 FP R/W 0.00
2681 A79 A2 - Calibration Measured 12 FP R/W 0.00
1
The Calibration Type register must be congured using ModWorX Pro. This register denes the type and
number of calibration points used. If altered manually, calibration points must be entered in ascending order.
Digital Input Conguration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2900 B54 Digital Mode U16 R/W 0
Flow Run 1 Conguration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
3000 BB8 FR1 Volume Units
See Units Table
U16 R/W 201
3001 BB9 FR1 Time Base U16 R/W 3
3002 BBA FR1 Flow Calculation Period
(Number of seconds for each
calculation)
U16 R/W 60
3003 BBB FR1 Dampening Factor U16 R/W 0
